CP-UVC-TC4K08ZL10H-VD
- 1/2” 8Megapixel progressive scan CMOS (1.27cm)
- Max. 15fps@3840×2160
- 3.7-11mm motorized lens
- Up to 500m transmission with RG59 coaxial cable
- WDR(120dB), Day/Night(ICR), 2D/3D-DNR, AWB, AGC, BLC, HLC
- 3x optical motorized zoom lens
- IR Range of 100 Mtrs.
- IP67, IK10
Description
| Image Sensor | 1/2” 8Megapixel progressive scan CMOS (1.27cm) |
| Minimum Illumination | 0.01Lux/F1.5(Color), 30IRE,0lux/F1.5(B/W) |
| Effective Pixels | 3840(H)×2160(V), 8MP |
| Shutter Speed | 1/1s~1/100,00s |
| White Balance | Auto / Manual |
| Lens | 3.7-11mm motorized Lens |
| Gain Control (AGC) | Auto |
| S/N Ratio | More than 65dB |
| Back Light Comp. | BLC / HLC / WDR |
| Video Streaming | PAL:3840×2160@12.5fps,2560×1440@25fps; NTSC:3840×2160@15fps,2560×1440@30fps |
| Video Output | 1-channel HDCVI video output & 1-channel CVBS video output |
| Resolution | 8MP (3840×2160) |
| ICR | Auto (ICR) / Manual |
| Audio Input | 1 channel |
| Alarm IN | 2 channel |
| Alarm Out | 1 channel |
| OSD | Multi-language |
| IR | IR Range of 100 Mtr. |
| Operating Temperature | -30°C~+60°C/ Less than 95%RH |
| Power Source | 12V DC ±25%/24V AC ±25% |
| Power Consumption | Max 18.4W |
| Weatherproof Standard | IP67 & IK10 |
| Dimension | 273.2mm×95.0mm×95.0mm |
| Weight | 1.08kg |
