CP-USC-DC10PL2-V3
- 1/2.7” 1MP PS CMOS Image Sensor (6.858 cm)
- Max 30fps@1MP
- DWDR, Day/Night (ICR), 2D-DNR, AWB, AGC, BLC
- 3.6mm fixed lens (2.8mm optional)
- IR Range of 20 Mtrs.
- OSD Menu, control over coaxial cable, 2D-DNR
- HD, SD and Two Analog format Output switchable
Description
| Image Sensor | 1/2.7” 1MP PS CMOS Image Sensor (6.858 cm) |
| Minimum Illumination | 0.04Lux/F2.4, 30IRE, 0Lux IR on |
| Shutter Speed | PAL: 1/25s–1/100000s ; NTSC: 1/30s–1/100000s |
| Lens | 3.6mm (2.8mm optional) |
| Lens Type | Fixed lens/ Fixed Iris |
| S/N Ratio | More than 65dB |
| Mount Type | Board-in |
| Max Aperture | F2.4 |
| Angle of View | H: 93°(57.6°) V: 48°(32°) |
| Close Focus Distance | 800mm (31.50”) |
| DORI Distance | 3.6mm- 51m (Detect) 20m (Observe) 10m (Recognize) 5m (Identify) 2.8mm- 51m (Detect) 20m (Observe) 10m (Recognize) 5m (Identify) |
| Back Light Compensation | BLC/ DWDR |
| White Balance | Auto / Manual |
| Video Streaming | 1MP@25/30fps |
| Video Output | 1-channel BNC high definition video output/ CVBS video output (Can switch) |
| ICR | Auto (ICR)/Manual |
| IR | IR Range of 20 Mtr., Smart IR |
| Gain Control (AGC) | Auto / Manual |
| OSD | Multi-language |
| Smart IR | Auto/ Manual |
| Casing | Plastic |
| Operating Temperature | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH |
| Power Source | 12V DC ±30% |
| Power Consumption | Max 2.3W (12V DC, IR on) |
| Dimension | 85mm×85mm×69mm |
| Weight | 0.09Kg. |
